T24Log100 – Data Logging & Visualisation Software
The Mantracourt T24Log100 is a free 100-channel data logging and visualisation software for the T24 wireless telemetry range. Running on Windows 7 through 11, it logs data to CSV, supports graphical mapping pages, visual and audible alarms, a built-in web server for remote viewing on tablets and smartphones, and a Centre of Gravity (COG) calculation function.
PRODUCT DETAILS
T24Log100 is a free data logging and visualisation software, designed to work with the full T24 wireless telemetry sensor transmitter range. It allows engineers, researchers, and system integrators to monitor and log up to 100 channels of wireless instrumentation data simultaneously — making it equally suited to large-scale structural monitoring projects, motorsport vehicle setup, industrial process supervision, and multi-point load measurement systems.
Each display channel can be configured with user-defined algorithms to calculate sums, differences, and other mathematical functions across multiple transmitters — for example, combining readings from several load cells into a total system weight. Up to eight graphical pages can be built using imported images (JPG, GIF, PDF, DXF), with drag-and-drop placement of customisable readouts and alarm indicators. The integrated web server streams a live summary view to any browser-connected device on the same network, including tablets and smartphones, enabling remote monitoring without additional software. Data is logged to CSV format on demand, at timed intervals, or automatically on overload conditions.
The Centre of Gravity (COG) function allows users to calculate and display the COG position from up to eight weight data sources — a capability used internationally by motorsport teams for vehicle setup optimisation prior to competition.
Most Common Applications: Multi-point load monitoring on structures and platforms, COG analysis, industrial process supervision, data logging.
| Compatible Hardware | Mantracourt T24 wireless telemetry sensor transmitter range |
|---|---|
| Platform | Windows 7, 8, 10, 11 (32-bit software, runs on 32-bit or 64-bit OS) |
| License | Freeware (free to download and distribute under freeware terms) |
| Channels | Up to 100 channels |
| Communication Interface | T24 2.4 GHz wireless via T24 base station (e.g. T24-BSu or T24-BSi) |
| Key Functions | Data logging (on demand, timed, on overload), graphical mapping pages, user-defined algorithms, visual and audible alarms, built-in web server, Centre of Gravity (COG) calculation, zoom-in channel history (10,000 points), customisable branding, report generation |
| Printer Option | – |
| System Requirements | Computer: Windows 7 or higher, 1 GHz processor, 8GB RAM, T24 base station required |
