WPBR 1063 Single-Ended Beam Weigh Bar
The Group Four WPBR 1063 is a specially designed stainless steel weigh bar rated to 22,500 lb (10,206 kg) with IP68 hermetic protection and a full scale output of 1.125 mV/V ±0.1%. Built for heavy-duty agricultural and industrial floor scale applications including large grain carts, feed mixers, fertilizer and manure spreaders, it delivers dependable high-capacity load measurement in demanding outdoor and wash-down environments.
PRODUCT DETAILS
The WPBR 1063 is a high-capacity stainless steel weigh bar providing accurate load measurement at 22,500 lb (10,206 kg) in agricultural and industrial environments where environmental durability is as critical as weighing performance. Sealed to IP68 with a dirt-repelling body design, it is built to withstand the moisture, grain dust, fertilizer, and manure typical of large grain cart, feed mixer, and manure spreader applications. Full-scale output is 1.125 mV/V ±0.1% with an excitation range of 5 to 15 VDC and a compensated temperature range of -10°C to +40°C (14°F to 104°F), with an operating range extending to -20°C to +65°C (-4°F to 149°F) for cold-climate field use. The 30 ft (9.1 m) 22 AWG 4-core shielded PVC cable provides ample reach for large agricultural equipment. Ultimate load rating is 200% of full scale, and safe overload is 150%, providing meaningful protection against the shock loading common in agricultural weighing applications.
Most Common Applications: Large grain cart and gravity cart weighing, heavy-duty feed mixer scales, fertilizer and manure spreader weighing, heavy agricultural and industrial floor scales, high-capacity wash-down platform scales.
| Capacities | 22,500 lb (10,206 kg) |
|---|---|
| Combined Error | – |
| Non-Linearity | ≤ ±0.15% FS |
| Safe Overload | 150% of full scale |
| Ultimate Overload | 200% of full scale |
| Full Scale Output | 1.125 mV/V ±0.1% |
| Maximum Excitation | 15 VDC |
| Input Resistance | 386 Ω ±30 |
| Output Resistance | 350 Ω ±5 |
| Operating Temperature | −20°C to +65°C (−4°F to +149°F) |
| Compensated Temperature | −10°C to +40°C (14°F to +104°F) |
| Sealing Standard | IP68 |
| Material | Stainless Steel |
| Protective Coating | – |
