T24-GW1 Wireless Gateway
The Mantracourt T24-GW1 is an IP67/NEMA 4 wireless gateway that aggregates data from up to 100 T24 transmitter modules and delivers it via Modbus RTU or ASCII serial protocol over RS232/RS485, enabling direct integration with PLCs, DAQ systems, and industrial automation platforms.
PRODUCT DETAILS
The T24-GW1 is the industrial integration backbone of the T24 wireless telemetry system. Where the T24-SO handles up to 8 transmitters for printing and display, the T24-GW1 scales to 100 simultaneous T24 transmitter channels, delivering their data to any Modbus RTU-capable PLC, LabVIEW DAQ system, DASYLab installation, or custom serial application. Its standard Modbus RTU protocol means engineers can map wireless sensor data — load, pressure, torque, strain, and more — directly into existing automation infrastructure as if it were a conventional wired instrument.
RS 232 connectivity supports point-to-point, while RS 485 supports multi-drop network topologies. Wake, sleep, and keep-awake commands for T24 transmitter modules are supported directly through the gateway, enabling centralized power management of large sensor arrays from within the host PLC or software environment. Configuration is handled through the free T24 Toolkit software.
Housed in an IP67/NEMA 4 enclosure and powered from a wide-range 9 to 32 VDC supply, the T24-GW1 is suited to permanent installation in industrial control panels, outdoor junction boxes, and mobile monitoring trailers across Original Equipment Manufacturer (Original Equipment Manufacturer (OEM)), construction, Boat Lifting & Building, and other sectors.
Most Common Applications: PLC and SCADA Modbus integration, large-scale multi-point load and process monitoring, industrial automation retrofit, centralized wireless sensor management in plant and field environments.
| Radio Frequency | 2.4 GHz |
|---|---|
| Wireless Range | Up to 2,624 ft (800 m) |
| Power Supply | 9 to 32 VDC |
| Operating Temperature | −20°C to +55°C (−4°F to +131°F) |
| Storage Temperature | −40°C to +85°C (−40°F to +185°F) |
| Maximum Humidity | 95% non-condensing |
| IP Rating | IP67 / NEMA 4 |
| Dimensions | 6.5 × 3.3 × 2.2 in (164 × 84 × 57 mm) |
