FMFS4 Fixed Mounting Foot

IMAGES

The Anyload FMFS4 is a fixed mounting foot in 17-4PH and 304 stainless steel with capacities from 100 lb to 10,000 lb (45 kg to 4,536 kg), available in imperial (1/2″, 3/4″) threads. Its rigid, low-profile design suits washdown and corrosive-environment floor scale and platform scale assemblies.

PRODUCT DETAILS

The FMFS4 is the 17-4PH and 304 stainless steel variant of the FMF fixed mounting foot series. It shares the same rigid, non-articulating base and low-profile geometry – 64.5 to 76.0 mm (2.54 to 2.99 in) total height – but is constructed from 17-4PH precipitation-hardened stainless steel and 304 stainless steel for superior corrosion resistance. Suited for food processing, chemical processing, and general washdown environments where a fixed foot and stainless construction are both required. Available in imperial (1/2″-20 UNF, 3/4″-16 UNF) threads, covering 100 lb to 10,000 lb (45 kg to 4,536 kg).

Most Common Applications: Food processing and washdown floor scales, corrosive-environment platform scale assemblies.

Max Static Load

45 kg (100 lb) to 4,536 kg (10,000 lb) – individual capacities:

  • FMFS460-1/2: 500-SE5,000 lb
  • FMFS470-3/4: 5,000-10,000 lb
Thread Sizes

1/2″-20 UNF; 3/4″-16 UNF

Material

17-4PH and 304 Stainless Steel
