FMF Fixed Mounting Foot

IMAGES

The Anyload FMF is a fixed mounting foot in alloy steel with capacities from 100 lb to 10,000 lb (45 kg to 4,536 kg), available in imperial (1/2″, 3/4″) threads. Its rigid, low-profile design suits floor scale and platform scale assemblies where a non-articulating foot is specified.

PRODUCT DETAILS

The FMF is a fixed, non-articulating mounting foot in alloy steel for floor scale and platform scale assemblies. Unlike the active AMF-F series, the FMF has a rigid base that does not articulate – it is the choice for applications where a fixed foot is specified or where the scale structure and floor surface are already well-aligned. Its low profile of 64.5 to 76.0 mm (2.54 to 2.99 in) minimizes the clearance required beneath the scale structure. Available in imperial (1/2″-20 UNF, 3/4″-16 UNF) threads, covering 100 lb to 10,000 lb (45 kg to 4,536 kg).

Most Common Applications: Floor scale and platform scale assemblies with well-aligned mounting surfaces, general-purpose multi-cell weighing structures specifying a fixed foot.

Max Static Load

45 kg (100 lb) to 4,536 kg (10,000 lb) – individual capacities:

  • FMF60-1/2: 500-SE5,000 lb
  • FMF70-3/4: 5,000-10,000 lb
Thread Sizes

1/2″-20 UNF; 3/4″-16 UNF

Material

Alloy steel
