112BA Aluminum Torque Load Cell
The Anyload 112BA is a compact aluminum reaction torque sensor available in capacities from 20 in-oz to 100 in-lb (0.14 Nm to 11.3 Nm), rated IP65. Its inline threaded mounting design suits OEM torque gauges, handheld testing devices, small motor characterization, and quality control verification systems requiring accurate low-range torque measurement. ATEX certified and FM Approved versions are available upon request.
PRODUCT DETAILS
The 112BA is a precision compact aluminum reaction torque sensor engineered for accurate, repeatable measurement of low-range rotational forces in OEM instruments, test equipment, and quality control systems. Available from 20 in-oz to 100 in-lb (0.14 Nm to 11.3 Nm), the 112BA covers the torque ranges most commonly encountered in handheld torque gauges, small electric motor characterization, fastener torque verification, gearbox component evaluation, and laboratory force measurement instruments. Its inline threaded mounting geometry integrates directly into torque gauge handles, test fixtures, and automated measurement systems without requiring bulky external brackets or adapters.
The 112BA’s millivolt/volt output connects to signal conditioners, amplifiers, and data acquisition systems for display and recording of torque values, and is compatible with 4–20 mA transmitters for integration with PLC-based process monitoring and quality control systems. No cable is included, the sensor terminates to a connector for flexible wiring to the application’s instrument. The IP65 aluminum clear-anodized construction provides reliable performance in laboratory, light industrial, and commercial test environments.
Most Common Applications: Handheld torque gauges, small electric motor characterization, fastener torque testing, laboratory torque calibration, OEM precision instrumentation, quality control torque verification.
| Capacities | 20 in-oz, 50 in-oz, 12 in-lb, 50 in-lb, 100 in-lb, 0.14 Nm, 0.35 Nm, 1.5 Nm, 5.6 Nm, 11.3 Nm |
|---|---|
| Combined Error | – |
| Non-Linearity | < ±0.2% |
| Safe Overload | 150% of full scale |
| Ultimate Overload | 300% of full scale |
| Full Scale Output | 2.0 mV/V ± 20% |
| Maximum Excitation | 10 V DC (15 V Maximum) |
| Bridge Resistance | 1000 Ω ± 50 (Input); 1000 Ω ± 5 (Output) |
| Operating Temperature | −10°C to 40°C (14°F to 211°F) |
| Compensated Temperature | – |
| Sealing Standard | IP65 Environmentally Sealed |
| Material | Aluminum |
| Protective Coating | Clear Anodized |
