RAMP-17 Floor Scale Ramp

IMAGES

The Anyload RAMP-17 is a mild steel floor scale ramp with a rugged checker plate surface, available in six size configurations from 3×3 ft to 5×4 ft (924 mm to 1,510 mm wide), designed to provide safe and easy access for wheeled loads onto floor scales. Includes L-shape base mounting plates and hardware.

PRODUCT DETAILS

The RAMP-17 floor scale ramp provides a safe, stable transition surface for mobile loads onto floor scales. Constructed from mild steel with a rugged checker plate surface, it is built to withstand the repeated impact and rolling stress of busy industrial and commercial environments. The surface is finished with a high-quality industrial paint coating for corrosion resistance and long service life.

Most Common Applications: Warehouse and distribution center floor scales, Original Equipment Manufacturer (OEM), plant weighing stations, food processing and agricultural receiving scales, logistics and freight weighing, anywhere wheeled or pallet-based loads need to be driven or rolled onto a floor scale platform.

Models

RAMP3×3-17, RAMP3×4-17, RAMP4×3-17, RAMP4×4-17, RAMP5×3-17, RAMP5×4-17

Construction

Mild steel

Surface Finish

High-quality industrial paint over checker plate surface

Mounting Hardware

Includes 2× L-shape base mounting plates, 4× M10×30 mm nuts and bolts
