B24-SSBC-A Bluetooth Strain Bridge Transmitter
The Mantracourt B24-SSBC-A is a Bluetooth Low Energy (BLE) strain bridge transmitter in a compact IP67 C style enclosure with an integrated battery holder for two AA batteries. It connects directly to load cells and strain gauges (85 to 5,000 Ω), delivers up to 17.5-bit wireless measurements to iOS and Android devices, and carries FCC and Industry Canada approval.
PRODUCT DETAILS
The B24-SSBC-A is the field-ready enclosed version of the B24-SSB Bluetooth strain bridge transmitter, packaged in a compact 3.15 x 2.44 x 1.34 in (80 x 62 x 34 mm) IP67-rated ‘C’ style enclosure with an integrated AA battery holder – ready to mount and deploy without any additional housing or wiring enclosure. It connects to any 4-wire strain bridge transducer between 85 and 5,000 Ω and transmits high-quality BLE measurements wirelessly to iOS and Android devices over ranges of 100 to 295 ft (30 to 90 m) line-of-sight.
The B24-SSBC-A achieves noise-free resolution of 1 in 92,000 counts (16.5-bit) with a 3 mV/V sensor and 1 in 184,000 counts (17.5-bit) with a 6 mV/V sensor, with four sensitivity range settings (±6, ±12, ±24, ±48 mV/V) accommodating a wide variety of load cells, torque sensors, and strain gauges. Two AA batteries power the unit for up to 10 months of continuous operation at 1 sample per second. Advanced PIN protection for configuration, viewing, and calibration prevents unauthorized access in multi-user or customer-deployed applications.
The free iOS and Android B24 app enables dashboard creation with digital displays, gauges, tanks, and charts, with readings definable as mathematical expressions across multiple transmitters for multi-point measurement systems.
Most Common Applications: Portable crane and rigging scale systems, field service force and weight measurement, structural load testing, wireless torque and tension monitoring, Original Equipment Manufacturer (OEM) portable weighing instruments.
| Input Channels | – |
|---|---|
| Load Cell Inputs | 1 strain gauge bridge (85 to 5000 Ω) |
| Output Signal | – |
| Communication | Bluetooth Low Energy, range 100 to 295 ft (30 to 90 m) line-of-sight |
| Relay Outputs | – |
| Digital Inputs | – |
| Display | – |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Conversion per second | – |
| Power Supply | 2x AA batteries |
| IP Rating | IP67 |
| Dimensions | 3.15 x 2.44 x 1.34 in (80 x 62 x 34 mm) |
| Approvals | FCC, IC , TELEC |
